Ce/RoHS 3-24W Square Ceiling LED Panel Light
Specifications:1.Sanan SMD 28352. 80LM/W CRI>803.CE RoHS, 5years warraty Features:1.Ultra slim design2.High brightness 2835 chip,Up to 26 lumen/chip3.High efficiency isolated driver, Constant Current Control IC for Transmission4.Over 90% light transmission makes the light softly and brightly5.Low......
Send Inquiry
Product Description
Specifications:
1.Sanan SMD 28352. 80LM/W CRI>80
3.CE RoHS, 5years warraty
Features:
1.Ultra slim design
2.High brightness 2835 chip,Up to 26 lumen/chip
3.High efficiency isolated driver, Constant Current Control IC for Transmission
4.Over 90% light transmission makes the light softly and brightly
5.Low maintenance cost. Life span: >50,000 hours
6.Instant on no flicker or hum
7.Emit NO UV or IR radiation, environmentally friendly
8.Universal input voltages available for North America, Latin America, Europe, Asia
9.Up to 5 years warranty base on different price and products
10.CE&ROHS approved
11.Power:3W/4W/6W/9W/12W/15W/18W/20W/24W
12.Color temperature:2800-7000
13.Lead time,1000-10000 within 7days,10,000-30,000 within 15days
| Power | Shape | Size(mm) | Hole size(mm) | Number of lamp beads | Color temperature | Lamp luminous flux(lm) | CRI(Ra>) | CCT | Input voltage(V) |
| 3W | Round or square | 85 | 70 | 15pcs | Cool white natural white warm white | 200lm+ | 80 | 2700-7000K | 85~265 |
| 4W | 105 | 95 | 20pcs | 290lm+ | |||||
| 6W | 120 | 105 | 30pcs | 440lm+ | |||||
| 9W | 150 | 130 | 45pcs | 660lm+ | |||||
| 12W | 170 | 155 | 60pcs | 890lm+ | |||||
| 15W | 190 | 185 | 75pcs | 1200lm+ | |||||
| 18W | 225 | 210 | 90pcs | 1600lm+ | |||||
| 20W | 245 | 230 | 100pcs | 1800lm+ | |||||
| 24W | 295 | 280 | 120pcs | 2180lm+ |
